90° HOSE FITTINGS WITH MALE THREAD

CODE	F	A (mm)	B (mm)	C (mm)	D (mm)
01011001	G 3/8″	13	16	41	45
01011002	G 3/8″	16	16	41	48
01011010	G 1/2″	10	18	44	45
01011011	G 1/2″	13	18	44	45
01011012	G 1/2″	16	18	44	48
01011013	G 1/2″	20	18	44	53
01011021	G 3/4″	13	22	50	45
01011022	G 3/4″	16	22	50	48
01011023	G 3/4″	20	22	50	53
01011024	G 3/4″	25	22	55	53
01011031	G 1″	20	22	50	53
01011032	G 1″	25	22	59	53
01011033	G 1″	30	22	60	60
01011034	G 1″	32	22	60	60
01011041	G 1 1/4″	25	24	65,5	53
01011042	G 1 1/4″	30	24	62	60
01011043	G 1 1/4″	32	24	62	60
01011044	G 1 1/4″	35	24	70	80
01011045	G 1 1/4″	38	24	70	84,5
01011046	G 1 1/4″	40	24	70	84,5
01011051	G 1 1/2″	30	24	62	60
01011052	G 1 1/2″	32	24	62	60
01011053	G 1 1/2″	35	24	70	80
01011054	G 1 1/2″	38	24	70	84,5
01011055	G 1 1/2″	40	24	70	84,5
01011061	G 2″	50	27	88	89
01011062	G 2″	52	27	88	89

CODE	F	A (mm)	B (mm)	C (mm)	D (mm)
01011016	G 1/2″	13	27	50	45
01011017	G 1/2″	16	27	50	48
01011018	G 1/2″	20	27	50	53

90° HOSE FITTINGS WITH MALE THREAD
